• Units can be mounted vertically or horizontally.
• Top or bottom access options available
• Bottom inlet also available on request.
• Roof mounted models with removable discharge cowl
• All units are fitted with pre-wired controls (available with no controls at special request)
• Designed to work with BMS systems as below:
  • Fault Out
  • VFC Enable
  • VFC Boost
  • Remote speed control

Available accessories

• Silencers
• Powder coated silencers
• Filter boxes
• AV mounts
• Duct clamps

• Units constructed from galvanised steel 0.9mm to 1.2 mm depending on the model
• Roof mounted models powder coated.
• Units are lined with 20mm Barafoam "O" class liner for reduced noise breakout
• A 6mm barrier mat layer incorporated in the liner significantly reduces noise breakout

ErP compliant 2009/125/EC

ACFS 150-EC ACFS 200-EC ACFS 250-EC ACFS 315-EC ACFS 350-EC ACFS 450-EC ACFS 560-EC

RMS 150-EC RMS 200-EC RMS 250-EC RMS 315-EC RMS 350-EC RMS 450-EC RMS 560-EC
