• high pressure duct fan to exhaust air and fumes through long lengths of rigid or flexible ducting
• hole diameter 4"/10cm
• integral backdraught shutter
• anti-vibration gasket
• for window installation use AWK10/4 or AWK10/4DG and remove backdraught shutter
• adjustable timer - 3-15 minutes
• dynamic humidistat with night time setback and anti-hunting device
• humidistat model with neon to show fan in manual operation
• easy plasterboard ceiling installation with (optional) Ceiling Ring
• easy wiring with quick fit terminal block
• whisper quiet operation
• IPX4 - Splashproof - can safely be installed in Zones I and II

• casings from shockproof and heat resistant plastics
• double insulated motors of shaded pole type mounted on self-lubricating, sealed ball bearings for long life
• motors incorporate thermal cut-out
• maximum ambient temperature - 40°C

• IEC60335-2-80
• LVD2006/95/CE
• EMC2014/30/UE (European Directive

against radio interference and electromagnetic compatibility)

• CE Marked

• AMF100T - overrun timer

Supply and install a Vectaire AMF100T high pressure duct fan for toilets, shower-rooms, bathrooms and utility rooms as supplied by Vectaire Ltd, Lincoln Road, Cressex Business Park, High Wycombe, Bucks, HP12 3RH. This fan is to be suitable for installation either in a ceiling, wall or window (with the appropriate accessories). The fan should be complete with an integral timer adjustable from between three and fifteen minutes, have an integral back-draught shutter and an anti-vibration gasket. The fan casing should be made of shockproof and heat resistant plastics, contain a motor with sealed, self-lubricating ball bearings and be protected with a thermal cut-out. The fan should be double insulated, and be suitable for installation for Zones I and II. Fan to comply with all current IEE, EC and Building Regulations requirements for installation into a toilet, shower-room, bathroom or utility room.
