• axial fans to exhaust air and fumes directly outside or through short lengths of ducting
• with passive infra red sensor
• new, ultra modern, technically innovative
• streamlined for improved air flow
• indicator to show when operating
• incorporates backdraught shutter
• extremely quiet operation
• adjustable timer - 3-25 minutes
• wiring can be surface mounted or recessed
• easy electrical connection
• IPX4 - Splashproof - can safely be installed in Zones I and II

• casings from shockproof, high quality technopolymer
• double insulated motors of shaded pole type mounted on self-lubricating, sealed ball bearings for long life
• energy efficient design
• motors incorporate thermal cut-out
• maximum ambient temperature - 40°C

• EN60335-2-80
• EC Low Voltage Directive 73/23-93/68
• EC Directive EMC89/336
• CE marked
• Keymark Approved

• AS10PIR, 12PIR, 15PIR - passive infra red sensor, timer

Supply and install an AS15PIR axial fan as supplied by Vectaire Ltd, Lincoln Road, Cressex Business Park, High Wycombe, Bucks, HP12 3RH. The fan is to be suitable for installation either into a ceiling, wall or panel (with the appropriate accessories). It should have a passive infra red sensor with a 50 degree detection range. There should be a neon on the front of the fan to indicate when it is operating. The fan casing should be made of shockproof, high quality technopolymer, contain a motor with sealed, self-lubricating bearings, and be protected with a thermal cut-out. The fan should be double insulated and be suitable for installation into Zones I and II. The fan is to be CE marked and comply with current EC Low Voltage Directive EMC89/336 and with BSEN60529. The fan should finally be suitable for installation into public places
