• exhausts directly to the outside (through wall, or with medium length ducting - up to 6m)
• easy and economical to install and maintain
• runs continuously at pre-selected choice of two speeds (fixed at installation)
• Speed 1 operates at 13 l/s (factory set)
• Speed 2 operates at 19 l/s
• speed boosted to maximum (44 l/s) by::
  • remote switch/light switch
  • PIR sensor
  • DRH240 (dynamic remote humidistat)
• anti-vibration gasket
• patented anti-turbulence deflectors ensure very low noise levels and optimum performances
• energy saving ventilation
• extremely low running costs
• low carbon footprint
• 5 year warranty
• Vectaire Ltd can supply all accessories for use with these units, including product filters. air filter cassettes, silencers, fire dampers, air valves, ducting, outside grilles and wall cowls. Additionally, Vectaire offers a design service to ensure that the unit installed is the best possible to provide efficient, effective, low energy and low running cost ventilation. Vectaire can also organise installation, commissioning and maintenance of these products.
• These fans are NOT suitable for use with Gravity Grilles. They should be installed using either Cowls or Fixed Grilles. Only approved accessories should be used:

• shockproof, high quality technopolymer casing
• designed using latest wind tunnel technology and CFD simulations
• EC induction motor with thermal protection
• 43,000 hour life motors with maintenance free and long life ball bearings
• operates in ambient temperatures up to 40ºC
• double insulated - no earth required
• IPX4 Splashproof rated - can safely be installed in Zones I and II

• shockproof, high quality technopolymer casing
• designed using latest wind tunnel technology and CFD

simulations

• EC induction motor with thermal protection
• 43,000 hour life motors with maintenance free and long life ball bearings
• operates in ambient temperatures up to 40OC
• double insulated - no earth required
• IPX4 Splashproof rated - can safely be installed in Zones I and II

• EL1203 - 3 speed, continuous running
• EL1203DT - 3 speed, continuous running with comfort timer (timer does not activate unless fan has been running for 2 minutes to avoid unnecessary night-time operation).
• EL1203HDT - with humidistat, comfort timer

N.B timer adjustable from 0-30 mins humidistat adjustable from between 40% and 90% relative humidity

• THESE FANS SHOULD BE INSTALLED WITH EITHER A FIXED GRILLE OR COWL
